User’s Manual for Advantech SOM-A2552 series module V1.00
18
to PCMCIA attribute space.
54 LINEOUT_R AO Audio line-Out right channel -
55 nSA_SKT1_CD
1
I PCMCIA/CF slot 0 card detect pin No pulling
56 LINEOUT_L AO Audio line-Out left channel -
57 nSA_SKT0_CD
1
I PCMCIA/CF slot 1 card detect pin
1.
No pulling
58 AC97_LINEIN_
R
AI Audio line input right channel. -
59 nSA_SKT1_CE
1
O PCMCIA/CF slot 0 card enable pin
1.
No pulling
60 AC97_LINEIN_
L
AI Audio line input left channel. -
61 nSA_SKT0_CE
1
O PCMCIA/CF slot 0 card enable pin
1.
No pulling
62 MIC_IN AI First Microphone input -
63 nSA_SKT1_CE
2
O PCMCIA/CF slot 1 card enable pin
2.
No pulling
64 GND P Ground -
65 SA_SKT1_VCC P PCMCIA/CF slot 1 power pin -
66 nSA_SKT0_VS
1
I PCMCIA/CF slot 0 voltage sense
pin 1.
Pull high with
10Kohm
67 nSA_SKT1_VS
1
I PCMCIA/CF slot 1 voltage sense
pin 1.
Pull high with
10Kohm
68 nSA_SKT0_CE
2
O PCMCIA/CF slot 0 card enable pin
2.
No pulling
69 SA_SKT1_RDY I PCMCIA/CF slot 1 ready pin. Pull high with
10Kohm
70 SA_SKT0_RDY I PCMCIA/CF slot 0 ready pin. Pull high with
10Kohm
71 nSA_SKT0_VS
2
I PCMCIA/CF slot 0 voltage sense
pin 2.
Pull high with
10Kohm
72 nSA_SKT1_VS
2
I PCMCIA/CF slot 1 voltage sense
pin 2.
Pull high with
10Kohm
73 SA_SKT0_RST O PCMCIA/CF slot 0 reset pin. Pull high with
10Kohm
74 SA_SKT1_RST O PCMCIA/CF slot 1 reset pin. Pull high with
10Kohm
75 nSA_SKT0_W
AIT
I PCMCIA/CF slot 0 wait signals.
Driven low by the PCMCIA card to
extend the length of the transfers
to/from the PXA255 processor.
Pull high with
10Kohm
76 nSA_SKT1_CD
2
I PCMCIA/CF slot 1 card detect pin
2.
No pulling
77 nSA_SKT1_W
AIT
I PCMCIA/CF slot 1 wait signals.
Driven low by the PCMCIA card to
extend the length of the transfers
to/from the PXA255 processor.
Pull high with
10Kohm
78 nSA_SKT0_CD I PCMCIA/CF slot 0 card detect pin No pulling
