Connection Jacks (Side)
You can connect an A/V component that is used only occasionally, such as a camcorder
or video game. (For information on connecting equipment, see page 18.)
ΠAUDIO INPUT jacks
Used to connect the audio signals from a
camcorder or video game.
´ VIDEO INPUT jack
Used to connect a video signal from a camcorder
or video game.
ˇ SUPER VIDEO INPUT jack
S-Video signal from an S-VHS VCR or DVD
player.
Note: In S-Video mode, Audio Output depends
what kind of audio input source is connected to
the side audio input jacks (AV2).
TX-R2728G TX-R2734G / TX-R2735G
• Please be sure to match the color coded input terminals and cable jacks.
