SPECIFICATIONS
ABSOLUTE MAXIMUM RATINGS
INPUT VOLTAGE +12 TO +48 VDC
OUTPUT CURRENT 4 AMPS PEAK
PLATE TEMPERATURE 70° C
STORAGE TEMPERATURE 40° TO +125° C
INPUT CURRENT (PINS 1, 2, 4, 5) 15 mA Max
ELECTRICAL SPECIFICATIONS (TA=25 EEC, V+ = 40VDC)
ITEM TEST MIN TYP MAX UNI
CONDITION TS
Input Voltage 12 24 40 V
Phase Output Current RMS .4 3 A
Phase Output Current Peak 4 A
Quiescent Current Outputs Floating 85 mA
Active Power Iout=3 Amps RMS 12 W
Dissipation
Input Forward Current Input Pins 7 15 mA
1, 2 , 4, 5
Input Forward Voltage 1.5 1.7 V
Input Reverse 5 V
Breakdown Voltage
Output Current Fault, Fullstep 25 mA
Outputs
Collector-Emitter Fault Output 140 V
Voltage
Collector-Emitter Fault Output 0.2 V
Saturation Voltage Ics=25mA DC
Drain-Source Voltage Fullstep Output 100 V
Drain-Source on Fullstep Output .65 ohm
Resistance Ics=25mA DC s
