Specifications
11
11 Specifications
11.3 Standard Signal Mode Table
z
This product can be set to only one resolution for each screen size to obtain the optimum picture
quality due to the nature of the panel. Therefore, a resolution other than the specified resolution
may degrade the picture quality. To avoid this, it is recommended that you select the optimum
resolution specified for the screen size of your product.
z
Check the frequency when you exchange a CDT monitor (connected to a PC) for an LCD monitor.
If the LCD monitor does not support 85Hz, change the vertical frequency to 60Hz using the CDT
monitor before you exchange it with the LCD monitor.
If a signal that belongs to the following standard signal modes is transmitted from your PC, the screen will
automatically be adjusted. If the signal transmitted from the PC does not belong to the standard signal
modes, the screen may be blank even though the power LED turns on. In such a case, change the
settings according to the following table by referring to the graphics card user manual.
D-Sub, HDMI1, HDMI2
HDMI1, HDMI2
Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
Pixel Clock
(MHz)
Sync Polarity
(H/V)
IBM, 640 x 480, 60Hz 31.000 59.940 25.170 -/-
VESA, 800 x 600, 56Hz 35.156 56.000 36.000 +/+
VESA, 800 x 600, 60Hz 37.879 60.000 40.000 +/+
VESA, 1024 x 768, 60Hz 48.363 60.000 40.000 -/-
VESA, 1280 x 720, 60Hz 45.000 60.000 74.250 +/+
VESA, 1280 x 800, 60Hz 37.879 60.317 65.000 +/+
VESA, 1280 x 1024, 60Hz 63.981 60.000 108.000 +/+
VESA, 1440 x 900, 60Hz 55.935 59.887 106.500 -/+
VESA, 1600 x 900, 60Hz 60.000 60.000 108.000 +/+
VESA, 1680 x 1050, 60Hz 65.290 59.954 146.250 -/+
VESA, 1920 x 1080, 60Hz 67.500 60.000 148.500 +/+
Resolution
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
Pixel Clock
(MHz)
Sync Polarity
(H/V)
480p, 720 x 480, 60Hz 31.470 60.000 27.000 -/-
576p, 720 x 576, 50Hz 31.250 50.000 27.000 -/-
720p, 1280 x 720, 50Hz 37.500 50.000 74.250 +/+
720p, 1280 x 720, 60Hz 45.000 60.000 74.250 +/+
1080i, 1920 x 1080i, 50Hz 28.120 50.000 74.250 +/+
1080i, 1920 x 1080i, 60Hz 33.750 60.000 74.250 +/+
1080p, 1920 x 1080p, 50Hz 56.250 50.000 148.500 +/+
1080p, 1920 x 1080p, 60Hz 67.500 60.000 148.500 +/+
