Water inlet
Connect the water inlet hose to a separate
tap with a 3/4" thread.
The inlet hose is provided with a water stop
device, which protects against damage
caused by water leaks in the hose which
could develop due to natural ageing of the
hose. This fault is shown by a red sector in
the window “A”. Should this occur, turn the
water tap off and refer to your Service Cen-
tre to replace the hose.
The other end of the inlet hose which con-
nects to the machine can be turned in any
direction. Simply loosen the fitting, rotate
the hose and retighten the fitting, making
sure there are no water leaks.
The inlet hose must not be lengthened. If it
is too short and you do not wish to move
the tap, you will have to purchase a new, longer hose specially designed
for this type of use.
Water drainage
The end of the drain hose can be positioned
in three ways:
Hooked over the edge of a sink using the
plastic hose guide supplied with the
machine. In this case, make sure the end
cannot come unhooked when the machine
is emptying.
This could be done by tying it to the tap with a piece of string or
attaching it to the wall.
In a sink drain pipe branch. This branch must be above the trap so that
the bend is at least 60 cm above the ground.
Directly into a
drain pipe at a
height of not less
than 60 cm and
not more than
90 cm.
48
Installation
