Aga Ranges U107501-01 - Manual (Page 44)

44
Read all instructions before installing or using this appliance.
Installation Instructions
Save these instructions for future reference.
Schematic diagram of the Range
Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause
improper and dangerous operation. Verify proper operation after servicing.
AGA Legacy 36 Inch Circuit Key
Code Description Code Color
REC Right hand end cooktop element controller BK Black
RFC Right front cooktop element controller BL Blue
RRC Right rear cooktop element controller BR Brown
LFC Left front cooktop element controller GY Grey
LRC Left rear cooktop element controller O Orange
REE Right hand end cooktop element - 2200W R Red
RFE Right front cooktop element - 1700W V Violet
RRE Right rear cooktop element - 1200W W White
LFE Left front cooktop element - 1200W W/BK White & Black
LRE Left rear cooktop element - 1800 W Y Yellow
BRE Broiler Elements
BSB Broiler Switch Block
BTC Broiler Temperature Control
TCO Temperature Cut Out
OFM Oven Fan Motor
OLS Oven Light Switch
OVL Oven Light 120 Volts
NLI Neon Light
L2 L2 Supply (Red)
N Neutral Supply (White)
L1 L1 Supply (BlacK)
OTL Oven Temperature Control Left
LBE Left Oven Bottom Element
LTO Left Oven Top Element
LTI Left Oven Top Inner Element
LFE Left Oven Fan Element
LOS Left Oven Switch Block
TCK Oven Control Clock
CFM Cooling Fan Motor
OTR Oven Temperature Control Right
RSB Right Oven Switch Block
ROE Right Oven Fan element
