Unpacking
Front
Rear
Bottom
Ge nera l
BNC C onne cto rs (Option)
General
(The configuration at the back of the monitor may vary from product to product.)
1. Power port
Connect the power cord for your monitor to the power port on the back of
the monitor.
2. Signal Cable
Connect the signal cable to the video port on your computer, video board,
video card, or graphics card.
BNC Connectors (Option)
(The configuration at the back of the monitor may vary from product to product.)
1. Power port
Connect the power cord for your monitor to the power port on the back of
the monitor.
2. Signal port
Connect the signal cable to the 15-pin D-sub connector on the back of
your monitor.
3. BNC Connectors
(Option)
Connect the signal cable to the BNC signal port on the back of your
monitor.
Note: See
Connecting
the Monitor
for further information regarding cable connections.
SyncMaster 797MB/997MB
SyncMaster 997MB
