35
Parts List- Model 6804S8-S11
Key Description Quantity
1 Side Burner Cover 1
2 Side Burner Cooking Grid 1
3 Left Side Table 1
4 Side Burner Valve 1
5 Side Burner Knob Bezel 1
6 Control Knob 5
7 Side Burner 1
8 Ignition Box 1
9 Main Knob Bezel 4
10 Front Crossbar 1
11 Cylinder Wire guard 1
12 Cabinet Side Panel- LEFT 1
13 Cabinet Upright 1
14 Cylinder Retainer Bolt 1
15 Cabinet Bottom Panel 1
16 Cabinet Door- LEFT 1
17 Cabinet Door- RIGHT 1
18 Handle, Door 2
19 Hood Handle 1
20 Thermometer 1
21 Hood Bumper 2
22 Hood 1
23 Warming Rack 1
24 Main Cooking Grid 3
25 Flame Diffuser 4
26 Main Burner 4
27 Right Side Table 1
28 Electrode Assembly 2
29 Manifold Assembly 1
30 Control Panel 1
31 Bottom Panel 1
32 Cabinet Back Panel 1
33 Foil Pan 1
34 Grease Pan 1
35 Cabinet Side Panel- RIGHT 1
36 Cylinder Blocking Wire 1
37 Match Holder/Chain 1
38 Caster, Fixed 2
39 Caster, Locking Swivel 2
40 Manifold to SB valve Hose 1
41 Regulator 1
42 Center Wheel 1
43 1/4-20 x .50” S/S Bolt 27
44 1/4-20 S/S Hex Nut 9
45 1/4-20 x .60” S/S Bolt 16
46 5/32 x .47” S/S Bolt 4
47 5/32 x .31” S/S Bolt 20
48 5/32 S/S Hex Nut 1
49 Side Burner Electrode 1 (no pic)
