Model gmrs1500xtm (fcc license required) – Audiovox 1500XTM User Manual

Page 5

background image

5

1. Antenna

2. Function (F) Select/Key Lock

Button

3. External Microphone/Speaker

Jack

4. Transmit (Red) LED

5. Liquid Crystal Display (LCD)

6. Up Control /Volume Increase

Button

7. Power On/Off Button

8. Battery Charging Connector

9. Battery Compartment Door

10. Menu Scroll Buttons (Forward/Back)

11.

Down Control/Volume Decrease
Button

12. Battery Compartment Cover

Latch

13. Built-in Speaker

14. Monitor (M) Button

15. Belt Clip Stud

16. Push-To-Talk (PTT) Button

17. Built-In Microphone

1

1 (REF)

2

3

4

5

6

7

8

9

10

13

14

16

17

F

12

15

11

BOTTOM

TOP

Model GMRS1500XTM (FCC License Required)
