How to override automatic tuning parameters
It is possible to set or fine tune three mode parameters
manually on the 6050.
To manually enter parameters:
1) Press "Index" button until the LED for the desired
parameter lights.
2) Enter the new parameter using the up or down key.
3) Press the "enter" button.
The new parameters will now take control of the process.
To calculate the PID parameters without using the automatic
tuning mode, consult the Athena 6000/6200 instruction manual.
Reading automatically calculated PID parameters
Press the "index" key. The LED‘s in the "Index" display will
light in sequence, and as they change, the lower digital
display will show each parameter.
