Operator Manual – MX-206 Mixer

Introduction

Congratulations on your purchase of an Ashly MX-206 stereo mixer. In one compact rack-
mount package we have combined features, reliability, and sonic performance you have
come to expect from Ashly. Features of this unit include:

20dB input pad on each channel

Up to 60dB of mic preamp gain

Switchable +48V phantom power

Concentric level and pan control on each channel

Ultra low-noise summing amplifiers

Two 5-segment LED arrays

Stereo line level outputs on 1/4" connectors

Tape/CD inputs and outputs on RCA connectors

Transformer isolated 600 ohm outputs on XLR connectors

Professional quality 16mm metal shaft potentiometers on all controls

About Ashly

Ashly Audio was founded in 1974 by a group of recording engineers, sound professionals,
and electronics designers. The first products were custom consoles for friends and
associates, but business quickly grew. The philosophy established from the very beginning
holds true today: to offer only the highest quality audio tools at an affordable cost to the
professional user – ensuring reliability and long life. More than thirty years later, Ashly
remains committed to these principles.
