DSR Installer/User Guide
Appendix D: Technical Specifications
DSR Product Specifi cations
Server Ports
Number
DSR800:
8
DSR1010, 2010, 4010: 16
Types
DSRIQ-PS/2, DSRIQ-USB, DSRIQ-VSN (Sun VGA),
DSRIQ-WSN (Sun 13W3) and DSRIQ-SRL modules
Connectors
RJ-45
Sync Types
Separate horizontal and vertical
Plug and Play
DDC2B
Video Resolution
640 x 480 @ 75 Hz (Local Port and Remote
Port Minimum)
800 x 600 @ 75 Hz
960 x 700 @ 75 Hz
1024 x 768 @ 75 Hz
1280 x 1024 @ 75 Hz (Remote Port Maximum using
a DSRIQ)
1680 x 1280 @ 75 Hz (Local Port Maximum)
Supported Cabling
4-pair UTP CAT 5 or CAT 6, 10 meters
maximum length
Confi guration Port
Number
1
Type
Serial
RS-232
Connector
DB9
Male
Network Connection
Number
1
Type
Ethernet: IEEE 802.3, 10BaseT, Fast Ethernet:
IEEE 802.3U, 100BaseT
Connector
RJ-45
Local Port
Number
1
Type
PS/2 and VGA
Connectors
PS/2 MiniDIN and 15-pin D-Sub
Dimensions
Dimensions (H x W x D)
DSR800: 1.72 x 17.00 x 8.075 in; 1U form factor
(4.45 x 43.18 x 20.5 cm)
DSR1010, 2010, 4010: 1.72 x 17.00 x 11.00 in; 1U
form factor (4.45 x 43.18 x 27.94 cm)
Weight
8 lbs (3.6 kg) without cables
Heat Dissipation
92 Btu/hr
Airfl ow
8 cfm (DSR1010, 2010, 4010 only)
AC-input Power
DSR800: 25 W maximum
DSR1010, 2010, 4010: 40 W maximum
AC-input Range
100-240 VAC
AC-input Current Rating
DSR800: 0.5A
DSR1010, 2010, 4010: 1A
