V-MATRIX
1
TABLE OF CONTENTS
Page
PRECAUTIONS / SAFETY WARNINGS .............. 2
1.1 GENERAL ................................ ................. 2
1.2 INSTALLATION ................................ ......... 2
1.3 CLEANING ................................ ................ 2
1.4 FCC / CE NOTICE ................................ ..... 2
ABOUT YOUR VM2143VS ................................ .. 3
TECHNICAL SPECIFICATIONS ......................... 3
PRODUCT DESCRIPTION ................................ . 3
APPLICATION DIAGRAM................................ .... 4
D IAGRAM 1 : C ONNECTIONS ................................ 4
D IAGRAM 2 : AC C OUPLED /75 O HMS .................. 5
D IAGRAM 3 : DC C OUPLED /75 O HMS .................. 6
D IAGRAM 4 : AC C OUPLED /H IGH Z...................... 7
D IAGRAM 5 : DC C OUPLED /H IGH Z ..................... 8
D IAGRAM 6 : I NTERNAL V IEW .............................. 9
INSTALLING YOUR VM2143VS ........................ 10
OPERATION................................ ...................... 10
TROUBLESHOOTING GUIDE........................... 10
8.1 CARD LED'S ARE NOT ON..................... 10
8.2 POOR DISPLAY QUALITY ...................... 11
8.3 NO DISPLAY ................................ ........... 11
ALTINEX POLICY ................................ .............. 11
9.1 LIMITED WARRANTY/RETURN POLICY 11
9.2 CONTACT INFORMATION...................... 11
