VDIV10.1, VDIV2.1 Voltage Divider Terminal Input Modules
The following examples show the measurement instruction for each of the
different dataloggers to measure the battery voltage described above.
4.1.1 CR1000, CR800, CR850
Public BattVolt
VoltDiff (BattVolt,1,mV2500,1,True ,0,250,0.01,0)
4.1.2 CR3000, CR5000
Public BattVolt
VoltDiff (BattVolt,1,mV5000,1,True ,0,250,0.01,0)
4.1.3 CR9000(X)
VoltDiff(BattVolt, 1, mV5000, 5, 1, 1, 0, 0, 0.01, 0)
4.1.4 CR7
1: Volt (Diff) (P2)
1: 1
Reps
2: 7
± 1500 mV Slow Range
3: 1
In
Card
4: 1
DIFF
Channel
5: 1
Loc [ BattVolt ]
6: 0.01
Mult
7: 0
Offset
4.1.5 CR10(X)
1: Volt (Diff) (P2)
1: 1
Reps
2: 25
± 2500 mV 60 Hz Rejection Range
3: 1
DIFF
Channel
4: 1
Loc [ BattVolt ]
5: 0.01
Mult
6: 0
Offset
4.1.6 CR23X
1: Volt (Diff) (P2)
1: 1
Reps
2: 15
5000 mV, Fast Range
3: 1
DIFF
Channel
4: 1
Loc [ BattVolt ]
5: 0.01
Multiplier
6: 0
Offset
