P R O D U C T A P P L I C A T I O N S H E E T

S e i s m i c P r o d u c t s f o r R a c k S y s t e m s

Seismic Frame

®

Two-Post Rack

Supports patch panels and network switches in seismic hazard areas.
Rated for a 1,000 lb (453.6 kg) load per Network Equipment Building
Systems (NEBS) GR-63-CORE Zone 4 requirements.

Part Number

Description

13853-703

19”W x 7’H (2.1 m), 44 RMU,
Tapped #12-24 Zinc Rails, Black

13854-703

19”W x 7’H (2.1 m), 44 RMU,
Square-Punched Zinc Rails, Black

13855-703

19”W x 7’H (2.1 m), 44 RMU,
Tapped #12-24 Painted Rails, Black

13856-703

19”W x 7’H (2.1 m), 44 RMU,
Square-Punched Painted Rails, Black

13883-703

23”W x 7’H (2.1 m), 44 RMU,
Tapped #12-24 Zinc Rails, Black

13884-703

23”W x 7’H (2.1 m), 44 RMU,
Square-Punched Zinc Rails, Black

13885-703

23”W x 7’H (2.1 m), 44 RMU,
Tapped #12-24 Painted Rails, Black

13886-703

23”W x 7’H (2.1 m), 44 RMU,
Square-Punched Painted Rails, Black

Universal Earthquake Bracing Kit
Adjustable bracket for bracing an equipment rack or auxiliary frame to
the wall or ceiling to meet earthquake safety codes.

Part Number

Description

10562-001

Universal Earthquake Bracing Kit

Seismic Frame

®

Two-Post Rack Floor Anchor Kit

Set of four seismic-rated concrete floor anchors for Seismic Frame

®

Two-Post Rack.
Part Number

Description

13702-001

Concrete Floor Anchor Kit

All products quoted are subject to availability based on manufacturing capacity and shipping dates should be considered estimates only. While every

effort has been made to ensure the accuracy of all information, CPI does not accept liability for any errors or omissions and reserves the right to change

information and descriptions of listed services and products.

©2008 Chatsworth Products, Inc. All rights reserved. CPI, CPI Passive Cooling, Saf-T-Grip, Seismic Frame, SlimFrame and MegaFrame are

federally registered trademarks of Chatsworth Products, Inc. Cube-iT Plus, Evolution, Simply Efficient, TeraFrame and QuadraRack are

trademarks of Chatsworth Products, Inc. All other trademarks belong to their respective companies. MKT-60020-377 09/08

Note: Additional installation hardware is required.

Equipment and Tower CPU Adjustable Tie-Down Brackets
(for Two-Post Racks)
Rack-mount brackets that secure equipment to shelves.
Part Number

Description

11349-719

Desktop CPU Tie-Down Bracket, 19” Rack, Black

11349-723

Desktop CPU Tie-Down Bracket, 23” Rack, Black

12091-719

Variable Height Tie-Down Bracket, 19” Rack, Black

12091-723

Variable Height Tie-Down Bracket, 23” Rack, Black

12086-719

Tower CPU Tie-Down Bracket, 19” Rack, Black

12086-723

Tower CPU Tie-Down Bracket, 23” Rack, Black

Other colors available.

S e i s m i c P r o d u c t s f o r C a b l e R u n w a y

S e i s m i c P r o d u c t s f o r C a b i n e t S y s t e m s

Seismic Frame

®

Cabinet System

Supports computer, data storage and network equipment in seismic
hazard areas. Rated for an 800 lb (362.9 kg) load per NEBS
GR-63-CORE Zone 4 requirements.

Part Number

Description

11972-742

19”W x 36”D x 7’H (2.1 m), 43 RMU, Includes
Perforated Doors, Top and Side Panels, Black

11973-742

19”W x 36”D x 7’H (2.1 m), 43 RMU, Includes
Perforated Doors and Top Panel (No Side Panels)

11974-702

19”W x 36”D x 7’H (2.1 m), 43 RMU,
(No Doors, Top or Side Panels), Black

Other colors available.

Seismic Equipment Bracket for Cabinets
Rack-mount bracket that secures equipment to shelves.

Part Number

Description

14061-719

19”W x 1 RMU, Adjusts 15” to 32”D
(380 mm to 810 mm), Black

Adjustable Bracing Kit for Cabinets
Brace the top of the cabinet to a nearby wall.

Part Number

Description

12477-719

Adjusts 24” to 36”D (610 mm to 910 mm), Black

Splice Kits
Connect Cable Runway together.

Part Number

Description

11299-X01

Heavy-Duty Butt-Splice Kit

16299-X01

UL Classified Heavy-Duty Butt-Splice Kit

11298-001

Heavy-Duty Junction Splice Kit

16298-001

UL Classified Heavy-Duty Junction Splice Kit

Earthquake Bracing Kits
Stiffening brackets for threaded rod supports.

Part Number

Description

10695-001

Single Earthquake Brace

10696-001

Double Earthquake Brace

Cable Runway Wall Angle
L-shaped angle used with Earthquake Bracing Kits.

Part Number

Description

11420-101

1’L (0.3 m), Gray

11420-104

4’L (1.2 m), Gray

11420-108

8’L (2.4 m), Gray

11420-110

10’L (3.0 m), Gray

Other colors available. Widths ranging from 4” to 24” available.

Other colors available. Install using four seismic-rated concrete anchors (sold
separately - see below).

Includes four Hilti HSL-3 M 12/25 anchors.

Heavy Duty Equipment Shelf for 6” (150 mm) Channel
Use on 19”W Seismic Frame Two-Post Racks to support shelf-mount
equipment.

Part Number

Description

12293-719

19”W x 5 RMU, 20”D (450 mm)
Supports up to 200 lb (90.7 kg), Black

Other colors available.

Fixed Shelf
Use on 19”W Seismic Frame

®

Cabinets to support shelf-mount

equipment.

Part Number

Description

14070-719

19”W x 2 RMU, 29”D (740 mm)
Supports up to 200 lb (90.7 kg), Black

Other colors available.

Other colors available.

Other colors available.

Seismic Frame

®

Two-Post Rack Vertical Cabling Section

Provides a double-sided, front and rear cable pathway

Part Number

Description

13704-703

Vertical Cabling Section, Black

Other colors available. Other CPI cable managers can be mounted on Seismic Rack.
