Kinivo EBI-180 Extended Battery Case - Manual

Extended Battery Case EBI180
for iPhone 4S and iPhone 4
Specifications & User's Guide
Product specifications
Model EBI180
Input Voltage 5.0V/1.0A(Max)
Output
Voltage
5.0±0.25V/1.0A
Nominal
Capacity
5.8 Wh
Use for iPhone 4S, iPhone 4
Cell Type
Li-polymer
1850mAH
Dimensions
125.4(±0.8)*62(±
Color Black
Weight 72g
0.8)* 16.8(±0.2)mm
Package Contents
Kinivo EBI180 Battery Case
USB power cable
User's Guide
Top part of the case (spare)
Illustration
Figure 1
Figure 2
Installing iPhone into battery case
Gently pull and remove the top part of the
case (fig 2)
Slide iPhone into the battery part of the
case (fig 3)
Close the top part of the case
Charging EBI180 battery case
Connect the battery case to the included
USB charging cable.
Connect the USB end of the cable to any
USB charger or a computer's USB port.
This will start charging the battery case. It
will also charge the iPhone if it is installed
inside.
Note: The case can be charged with or
without the iPhone installed inside it.
Notes:
LED status while charging
CHG
Capacity
LED1 LED2 LED3 LED4
OFF OFF OFF
ON OFF OFF
ON ON OFF
Low
25%
50%
75% ON ON ON
FULL ON ON ON ON
BLINKING
BLINKING
BLINKING
BLINKING
DCHG
Capacity
LED1 LED2 LED3 LED4
Full ON ON ON ON
75% ON ON ON OFF
50% ON ON OFF OFF
25% ON OFF OFF OFF
Empty OFF OFF OFF OFF
LED status during regular use
1 year warranty
www.kinivo.com
Contact: [email protected]
www.kinivo.com
Email: [email protected]
Charging iPhone with EBI180
Press and hold on/off button (about 3 Sec)
to charge your iPhone from EBI180’s
battery.
Press and hold on/off button again (about 3
Sec) to power off the battery case when
iPhone is fully charged. This can save the
capacity of the built in battery for future use.
Press and release the on/off button to
check the EBI180's battery status.
Warranty
EBI180 is covered under 1 year limited
hardware warranty.
Please contact [email protected]
if you need assistance or if you have
any questions.
* Kinivo is a trademark of Kinivo LLC.
“Made for iPhone” means that an electronic
accessory has been designed to connect
specifically to iPhone and has been certified by
the developer to meet apple performance
standards
Apple is not responsble for the operation of this
device or its compliance with safety and
regulatory standards. Please note that the use
of this accessory with iPhone may affect
wireless performance.
iPhone is a trademark of Apple Inc., registered
in the US and other countries.
The iPhone will automatically stop charging
when the battery in the case has been
used up.
Use the included USB cable to charge and
sync the iPhone in the battery case
Figure 3
