3
2-2. Electrical Performance
Specification Model No.
Item SA-1000K-112 SA-1000K-124
Continuous Output Power 1000W
Maximum Output Power 1100W
Surge Rating (Max) 2000W
Input voltage 12V 24V
Output Voltage 100 / 110 / 120V +/- 5%
Frequency
(Switch Selectable)
50 / 60Hz +/- 0.05%
Output Waveform Pure Sine Wave ( THD < 3% )
Efficiency (full load) Max. *1 89.0% 92.0%
No Load Current Draw (Max.) 1.43A 0.75A
Stand-By Current Draw (Max.) 0.25A 0.15A
Input Voltage Regulation
10.5-15
VDC
21.0-30
VDC
Input Level Indicator
Red / Orange / Green LED
Load Level Indicator
Failure Indicator Red LED
Protection
Overload, Short Circuit, Reverse Polarity (Fuse),
Over / Under Input Voltage, Over Temperature.
Remote Control Unit S-R8, S-R6-12, S-R6-24 Optional
Safety Certification UL458
EMC FCC Class A
Operating Temperature Range 0 - 40
℃
Storage Temperature Range -30
℃ to 70℃
Cooling Loading controlled cooling fan
Dimensions 383(L)*182(W)*88(H)mm / 15.08(L)*7.17(W)*3.46(H) Inch
Weight 4 kg / 8.8 Lbs.
Note: The specifications are subject to change without notice.
