SPECIFICATIONS
NO. OF MODULES
2
3
4
5
INPUT VOLTAGE RANGE
105 TO 125 V AC, 60 HZ
INPUT CURRENT
8A
12A 16A 20A
OUTPUT VOLTAGE (At terminals L+ & L- , See page 7)
•
NOMINAL, VDC
13.8 V
•
NO LOAD, VDC
14 V
•
FULL LOAD, VDC
13.65 V 13.55 V 13.45 V 13.35 V
OUTPUT
REGULATION
1%
(At module output S5, S6—Fig. 1)
OUTPUT CURRENT
•
CONTINUOUS
40A
60A 80A 100 A
•
SURGE
46A
69A 92A 115A
OUTPUT CURRENT LIMIT
48A
72A 96A 120A
OUTPUT RIPPLE, PEAK TO PEAK
150mV
OUTPUT NOISE, PEAK TO PEAK
1V
0.9V 0.8V 0.7V
COOLING
FORCED
AIR,
2
FANS
OPERATING TEMPERATURE
0 TO 40 C
PROTECTIONS
•
SHORT CIRCUIT
YES
•
CURRENT LIMIT
YES
•
FAN FAILURE
LED AND BUZZER
•
INPUT SURGE SUPRESSION YES
FUSE / BREAKER
● MODULE FUSE – 250 V, 4 A
● UNIT HAS A BREAKER
250
V,
20
A
DIMENSIONS(19” Rack Mount, 2U height) 19” X 15.9” X 3.6”
POWER CORD
12 AWG / 3 CONDUCTOR
POWER CORD PLUG
•
SEC-100BRM
125V, 30A, NEMA L5-30P, TWIST LOCK TYPE
•
SEC-40BRM/60BRM/80BRM
125V, 20A, NEMA 5-20P
WEIGHT, LBS
20.5
22
23.5 25
NOTE:
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
SEC-40BRM SEC-60BRM SEC-80BRM SEC-100BRM
