SPECIFICATIONS
Model Nos. SEC-1235 No meters
SEC-1235M With Voltmeter and Ammeter
Nominal Input Voltage 120 VAC, 60 Hz (100 VAC to 130 VAC) – Factory preset
230 VAC, 50 Hz / 60 Hz (200 VAC to 260 VAC) – By internal
setting
Input current 7.5 A at 120 VAC, 60 Hz
3.5 A at 230 VAC 50 / 60 Hz.
Output Voltage 13.8 VDC
Output voltage adjustment 11.5 V to 15.5 V with the help of internal potentiometer
Output current 30 A continuous
Current limit 35 A, constant current limiting, auto recovery
No load current draw 120 mA at 120 VAC
Ripple 50 mV peak to peak
Noise 150 mV peak to peak
Peak Efficiency 85%
Cooling Temperature controlled fan
Output indications Voltmeter and Ammeter (only for SEC-1235M)
Protections against Overload, short circuit
Over temperature
Operating temperature 0° to 40° C
Safety Certification UL60950-1, E179076
EMI (Emissions) compliance: FCC Part 15 (B) for Class B devices
AC input connections Male AC inlet connector Type “IEC 320-C14”
Detachable AC power cord with:
- Female connector Type “IEC 320-C13” on one end to
mate with AC power inlet connector on the power supply
- Male, 2 pole 3 Wire grounding (3 prong) plug Type
“NEMA5-15P” on the other end for connection to the AC
outlet.
DC output connections RED (+) and BLACK (-) terminals with tubular hole and set
screw. Hole diameter 0.2 “, (5 mm). Includes a pair of copper
terminal lugs for crimping to output wires to the load
Input side fuse
For 120 VAC input: Rating 250 V, 8 A
(5 mmX20mm, glass ferrule, Manufacturer: Littel Fuse, Model No. 218008
delayed action)
For 230 VAC input: Rating - 250 V, 4A
Manufacturer: Ltttel Fuse, Model 218004
Weight 3.4 lbs
Dimensions (L X W X H) 8” X 7.3” X 2.5” for SEC-1235
8.4” X 7.3” X 2.5” for SEC-1235M
Note: The above specifications are subject to change without notice
