32
W
ALL
M
OUNTING
1. Install the supplied wall-mount screws by using the template. Refer to Install Wall-Mount
Screws below.
Install Wall-Mount Screws
2. Open the unit. Refer to “Open Unit” on page 3 .
3. Hang the unit on the wall and install Wall Mount Brackets. Refer to Hang Unit below.
Hang Unit
4. Close the unit. Refer to “Close Unit” on page 4 .
The ES700 should be mounted on 1/2 inch drywall using two ST 4x20 screws and
fasteners.
Be sure to keep about 6mm (1/4") of the screw head away from the wall. The
recommended height from the floor to the bottom of the unit is 45".
:$//
