12 Appendix
12.1 Specifications
12.1.1 Environmental
Table 54: Environmental Specifications
Standard Temperature Extended Temperature
Operating Temperature -20 ◦ C to +70 ◦ C -40 ◦ C to +85 ◦ C
Operating Relative Humidity 90% max non-condensing
Vibration (Operating) 4.9 m/s 2 XYZ directions
Vibration (Non-Operating) 19.6 m/s 2 XYZ directions
Shock (Operating) 29.4 m/s 2 XYZ directions
Shock (Non-Operating) 490 m/s 2 XYZ directions
12.1.2 Electrical
Table 55: Electrical Specifications
Standard Wide Voltage (V) Wide Voltage with Efficient
Switching Power Supply
(VPT)
Supply Voltage +5Vdc ±0.25V +9V to +15V +9V to +35V
Supply Power 110 mA typical
Inrush 275 mA
12.2 Optical Characteristics
Table 56: Optical Characteristics
Display Format 20 characters by 4 lines
Matrix Format 5 x 8
Display Area 70.8 x 20.90 mm
Character Size 2.4 x 4.70 mm (XxY)
Character Pitch 3.55 mm
Line Pitch 5.35 mm
Dot Size 0.55 0.55 mm (XxY)
Dot Pitch 0.60 x 0.60 mm (XxY)
Luminance 350cd /m 2 (100fL) min
Color of Illumination Blueish Green
