Command Summary 49
15.10 XModem
Filesystem
Download Dec
Hex
ASCII 254 222 133 6 48
FE DE 85 6 30
■ ▐ à
ACK 0
v8.3
Downloads the complete filesystem using the XModem Upload Protocol. A veritable heap of data, transmitted at a
decent pace.
Response Integer Size of the filesystem to download.
Byte(s) Filesystem data to download, an even multiple of 256 bytes.
15.11 XModem
File Upload Dec
Hex
ASCII 254 220 133 6 48
FE DC 85 6 30
■ ▄ à
ACK 0
File ID Type Size Data
File ID Type Size Data
File ID Type Size Data v8.3
This command will upload a single file to the display. Unlike the standard protocol, there is one XModem upload
command for all file types, see File Types for a complete list.
File ID Word Unique identification number for the file to upload.
Type Byte Type of file to upload, see File Types .
Size Double Size of the file to upload.
Data Byte(s) File data to upload, must be padded to an even multiple of 128 bytes.
15.12 XModem
File Download Dec
Hex
ASCII 254 221 133 6 48
FE DD 85 6 30
■ ▌ à
ACK 0
File ID Type
File ID Type
File ID Type v8.3
Downloads a single file from the display to the host using XModem protocol.
File ID Word Unique identification number for the file to download.
Type Byte Type of file to download, see File Types .
Response Double Size of the filesystem to download.
Byte(s) Filesystem data to download, an even multiple of 128 bytes, may be padded with 255s.
File Transfer Protocol
Once a bitmap or font file has been created and paired to its command it must be sent using a file
protocol developed specifically for Matrix Orbital displays. Once a file upload command has been sent
requesting a unique reference number and specifying the file size required, the display will respond
indicating whether it has enough room to save the file or not. As is the case throughout the upload
protocol, a response of 1 will indicate confirmation while an 8 corresponds to rejection and will
terminate the session.
Table 42: Upload Protocol Responses
Value Action Description
1 Acknowledged Transfer successful, upload continues
8 Not Acknowledged Transfer failed, abort upload
