7
INDICATION LIKELY REASON REMEDY
no power to valve power supply off check connection of power supply
power supply problem
disconnect GFM transducer from
power supply; remove the shorting
condition or check polarities; fuse
resets automatically
pc board defective
check power supply for appropriate
output
no response to
set point inadequate gas pressure return to factory for replacement
cable or connector malfunction apply appropriate gas pressure
cable or connector malfunction
check cables and all connections or
replace
set point is too low
(<2% of full scale)
re adjust set point
valve adjustment wrong re adjust valve
pc board defective return to factory for replacement
(f) TROUBLESHOOTING
f.1 Common Conditions
Your Solenoid Valve Driver Module was thoroughly checked at numerous quality
control points during and after manufacturing and assembly operations.
It was carefully packed to prevent damage during shipment. Should you feel that
the instrument is not functioning properly please check for the following com-
mon conditions first:
Are all cables connected correctly?
Is the power supply correctly selected according to requirements?
Were the connector pinouts matched properly? When interchanging with other
manufacturers' equipment, cables and connectors must be carefully wired for
correct pin configurations.
f.2 Troubleshooting Guide
