Aalborg PWM Paddle User Manual
Page 6
3
1
4
2
3
2
7
6
5
4.
PARTS
NOTE: Platinum RTD is not shown.
PARTS LIST
PARTS
PWMP MATERIALS
PWMT MATERIALS
1
LOWER BLOCK
POLYPROPYLENE
PVDF
2
JEWEL BEARING (2 required)
PVDF SAPPHIRE
3
PADDLE WHEEL
PVDF & NICKEL
TUNGSTEN CARBIDE
PVDF &
ZIRCONIA CERAMIC
4
LID
ACRYLIC
PVDF
5
SENSOR
NOT WETTED PART
6
SCREW 8-32 (4 required)
STAINLESS STEEL
7
O-RING
EPDM
PTFE
8
RTD (Not Shown)
STAINLESS STEEL CASING
