Microlab FC 362W User Manual

Page 4

auto detect the device, “SYNIC wireless audio” and install its driver.
b. Windows® operating system will then change the sound playback properties to the
“SYNIC wireless audio”. The blue LEDs will now blink slowly indicating both are paired
and on standby for data transfer.
c. Please start your audio media software and start the playback.
d. Next depress the side button of the USB dongle t ill the blue LED blinks quickly, then go
to the back of the main speaker and depress the rear pairing button till the blue LED
blinks quickly to activate the pairing sequence. Once paired, both LEDs will blink slowly
indicating successful connection.
f. The LED will illuminate steadily once music is played and music data being transmitted.
e. The pairing process is carried out once only. Subsequent uses are fully automatic
except for reinstallation of operating system. If t he playback is not started, the pairing
will not work.

Technical Information

Specifications

Frequently Asked Questions (FAQ)

Power LED won't light up

No Sound

One or more satellite no sound

Static sound heard when volume
knob is turned

Check if the system is powered on
Check the power plug well connected
Check if the audio source is working well
Check if the audio and speaker cables well connected
Check if the volume at right level
Check if the satellite cable well connected, and ensure source
connection is correctly inserted
Turn off the playback source first, then turn the speaker
volume knob several times. Playback again and monitor. The
static noise is due to dust, so simply turning the volume will
remove it easily

Any playback devices such as PC, notebook, CD/DVD player,
Media Players with 3.5mm stereo plug
Check if the source file is not corrupted, play a different song
and test
Check if the battery in the remote control
It is magnetically shielded so can be placed near LCD TV
Monitor without any distortion

What are the products supported ?

Sound is distorted

Remote control not working
Where to place this speaker

Amplifier

Speakers

Interfaces

Power

Dimensions

Output power: 54 Watt RMS
Power distribution: 15 Watt x 2 + 24 Watt RMS
Harmonic distortion: < 0.3% 1W 1kHz
Frequency response: 35Hz - 20kHz
Signal/Noise ratio: > 75 dB
Separation: > 45 dB

Tweeter driver type: 2.5"
Tweeter rated power: 15 Watt 2.4 ohm
Bass driver type: 6.5" with eAirbass
Bass rated power: 30 Watt 8 ohm
Frequency range: 35 Hz - 20 kHz

Output: RCA sockets x 3
Input: 3.5mm stereo, and 2RCA sockets
Wireless: Infrared remote control
2.4GHz: USB type A

Power supply: AC 220V - 240V ~ 50Hz, 200mA
or
AC100V - 120V ~ 60Hz, 460mA

Amplifier: 75 (W) x 200 (H) x 200 (D)mm
Subwoofer : 255 (W) x 255 (H) x 287 (D)mm
Speakers:

96 (W) x 263 (H) x 110 (D)mm

Product net weight: 8,80 kg

Problem

Solutions

Remote Control

Inserting batteries into the remote

VOL+

VOL-

RESET

INPUT

TREB+

BASS+

BASS-

TREB-

VOL-

VOL+

Mute

Reset

Input

Treble

Volume

Bass

Infrared lens

Opening

tab

1. Locate the side
tab of the remote
control
2. Press the tab
3. Pull the top apart to
expose the battery compartment

Note: Prolong un-use period, please remove
batteries to prevent leakage.

Please observe battery
orientation when inserting

Battery compartment

Wireless remote

2.4GHz USB dongle

USB type A interface

Pairing button
(depress tu pair with amplifier)

Ideal listening position and placement

FL -front left
FR -front right
SW -SUBWOOFER
A -amplifier

If the problem still exists, please contact the distributor or ask for professional service
