Right Speaker
Right Speaker
1. Wall hook
2. Audio cable
3. On/Off/Volume knob
4. Speaker stand
5. to left speaker
6. power cable
15. Attachments - Do not use attachments not recommended by the product manufactures, as they
may cause hazards.
16. Accessories - Do not place this product on an unstable cart, stand, tripod, bracket or table. The
product may fall, causing serious injury to a child or adult, and serious damage to the product. Use only
with a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product. Any
mounting of the product should follow the manufacturer's instructions and should use a mounting
accessory recommended by the manufacturer.
17. Moving the product - A product and cart combination should be moved with care. Quick stops,
excessive force and uneven surfaces may cause the product and cart combination to overturn.
18. Unused periods - The power cord of the appliance should be unplugged from the outlet during
lightning storms or when the apparatus is left unused for a long period of time.
19. Servicing - Do not attempt to service this product yourself, as opening or removing covers may
expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
20. Please remove the power plug form the main power source or wall power source when not in use.
When plugged in to a power source, the system is in standby mode, so the power is not entirely cut off.
21. Replacement parts - When replacement parts are required, ensure the service technician has used
replacement parts specified by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
22. Mains fuses - For continued protection against fire hazard, use fuses only of the correct type and
rating. The correct fuse specification for each voltage range is marked on the product.
23. Do not turn up the volume while listening to a section with very low level inputs or no audio signals. If
you do, the speaker may be damaged when a peak level section is suddenly played.
24. The only means of completely disconnecting the product from the power supply is by removing the
power cord from the wall outlet or the product. The wall outlet or the power cord entry to the product must
remain freely accessible at all times while the product is in use.
25. Try to install the product near a wall socket or extension cord and shall be easily accessible.
26. The highest environmental temperature suitable for this product is 40°C.
EN
3
Introduction
Compact and slim stereo system for notebook or desktop computer and digital media players such as
Mp3 or Mp4. Balanced and clear audio with minimum distortion free production.
Designed with portability in mind, the speakers have rear panels serving as foldable stands and storage
compartment for cables.
Comes with dual power supply options, USB or DC power.
Features
- USB llightweight speakers, perfect for travellers and portable use
- No battery or AC power required
- 2" x 2 quality stereo speaker drivers with collapsible stands
- Ideal for mulimedia use with 3.5mm stereo plug and side rotary volume knob
Packing list
You should find following items while unpacking:
Illustrations
Product connection and operation
EN
4
Satellites 2pcs
USB-to-DC
1pc
User manual 1pc
3
4
2 6
5
1
Back view
PC or Notebook
Mp3 / Mp4
Media player
CD / VCD / DVD
player
to USB port
for power
to left
speaker
Right speaker Left speaker
Connections
1. Connect the audio input cable plug from the right speaker to the audio output socket on the PC or any
media player.
2. Connect the USB plug of the power cable to the USB interface on your PC or any powered USB hub.
Next connect the DC plug to the DC input jack on the right speaker.
3. Turn on the power.
Operation
1. Turn on the speaker power by turning the volume knob.
2. Ensure the volume level is set to lowest first.
3. Start the playback device and song.
4. Slowly adjust the volume to your preferred volume level and enjoy.
Note: it is advisable not to turn the volume too loud or to its extreme volume limit to avoid damage to the
speaker driver material. Always adjust in slow increment.
