m15 VIBRATORY opinst.doc - 9/14/2010
1
BURR KING MFG. CO., INC.
122 0 TAMARA LANE
WARSAW MO 6 5355
W WW .BURRKING.COM
(660) 438-8998 (800) 621-2748
FAX (660) 438-8991
December 2009
Operating instructions for Model 15 VibraKING
®
The VibraKING 15 vibratory bowls are stand mounted vibratory processing machines. The bowls are
compatible with ceramic, plastic, shell, cob, and most other media types. The bowls include a port for fluid
induction, and a port for fluid draining. The bowls are excellent for de-burring, de-scaling, cleaning, surface
moderating, and polishing of metals, plastics, and other materials.
Performance features of the M15
Your machine may be configured to be used with the following power. Please refer to the product label on
the machine for the power requirements.
60 hertz, 110-120 VAC, single-phase electrical power
60 hertz, 208-240 VAC, single-phase electrical power
50 hertz, 208-240 VAC, single-phase electrical power
Avoid electrocution hazards . The M15 is not NEMA 4 or NEMA 4X rated. They
must not be used in a manner that allows fluids to enter the unit base, power cord,
on/off switch, or electrical plug. This machine must be installed with a GFCI outlet to
minimize the risk of electric shock or electrocution. If your machine is configured for
208-240 volts you should install a GFCI circuit in your electrical distribution panel.
• Vibratory amplitude is easily, and continuously adjustable from zero to full amplitude.
• Standard media discharge shoot
• An integrated 0-6 hour timer
• The machine may be operated with media/ part loads from light to full capacity without damage provided
the counterweights are adjusted for the load (see next page).
• A one-half horsepower AC motor rotating within a rotation range of 1500 to 1700 RPM (dependant on
the bowl load instilled) provides vibratory energy to the bowl.
At receipt and prior to using you VibraKING
®
bowl
Before leaving the Burr King factory your VibraKING
®
bowl was completely tested and inspected to assure
that is was complete, functional, damage free, and properly packaged for shipment. You should:
• inspect the equipment for completeness and shipping damage. If anything is missing contact you’re
equipment supplier, or Burr King Manufacturing. If there is shipping damage file a claim with the freight
carrier that delivered the bowl,
• read all instructions completely. If you have questions please contact your equipment supplier or Burr
King Manufacturing for assistance,
• verify that you have your media and compound of choice,
• locate the warranty card, complete it, and return it to Burr King Manufacturing. This will insure that we
can better assist you in the unlikely event you require warranty service.
Avoid electrocution hazards
. The M15 is not NEMA 4 or NEMA 4X rated.
They must not be used in a manner that allows fluids to enter the unit base, power
cord, on/off switch, or electrical plug.
Avoid fire and explosion hazards . The use of fluids other than water and
Burr King specified soaps in the bowl (or any associated fluid re-circulating system)
may create a fire/explosion hazard that could result in personal injury, or death. Use only clean water
with recommended soaps in your VibraKING
®
bowl and associated accessories.
