Burr King Model 1050 Tube Finisher User Manual
Page 8
NOTE:
*20-0007 & 20-0008 2&3 HP/ 3PH
*20-0013 & 20-0014 1-1.5 HP/ 1PH
*1039 2&3 HP/ 1&3 PH
*1039-1 1-1.5 HP/ 1PH
1050
ITEM NO. PART NUMBER
DESCRIPTION
QTY.
1
99-0024
BASE PLATE ASSEM.
1
2
99-0025
SUPPORT, MOTOR
1
3
MOTOR
CALL FACTORY
1
4
908
ADAPTER, C-FACE MOTOR
1
5
1-0003
BOLT, 3/8-16 x 1 1/4 HEX HEAD
4
6
17
WASHER, 960-616, AN
6
7
5-0014
WASHER, LOCK 3/8, INTERNAL STAR
4
8
42
WASHER, SAE, 3/8
6
9
920
STUD 3/8"x1 1/2", DOUBLE
2
10
99-0040
FRAME, ASSEMBLY
1
11
39
NUT, 3/8-24, JAM, ESNA, NTE
2
12
*20-0007
*20-0013
PULLEY, MICRO-V, 16G 2.4 x .875
PULLEY, 8 GROOVE/J, 2.5D x .984
1
13
25
SCREW, SET, 5/16-18 X 3/8, ALLEN
2
14
1033
MOUNT, BEARING
2
15
2-0026
SCREW, 1/4-28 x1, ALLEN CAP
6
16
11-0004
BEARING, BALL 62052RS TPI LLU
2
17
10-0003
CIRCLIP, 1" DIA
2
18
1034
SHROUD, BEARING, MOUNT
2
19
1-0021
SCREW, 1/4-28 x 1 3/4 ALLEN
6
20
1028-1
SHAFT
1
21
*20-0008
*20-0014
PULLEY, MICRO-V, 16G 1.98 x .984
PULLEY, 8 GROOVE/J, 2D x 5/8
1
22
*1039
*1039-1
BELT, MICRO-V, 16 GROOVE, 360J16
BELT, MICRO-V, 8 GROOVE, 360J8
1
23
2-0027
SCREW, 5/16-18 x 2, SHCS
5
25
1035-4
PLATE, LOGO
1
26
2-0028
SCREW, 1/4-28x1/2 BH
6
27
1030
FLANGE, WHEEL
2
28
1031
NUT, 3/4 x 16 RH, HEX
1
29
1029-8
GUARD, WHEEL
1
30
5-0008
WASHER, 1/4, LOCK, EXTERNAL
4
31
99-0026
BRACKET, SUPPORT
1
32
4
WASHER, 5/16 SAE ZINC PLTD
12
33
5-0017
WASHER, 5/16 LOCK, SPLIT
8
34
1-0044
BOLT, 5/16-24 x 3/4 HEX HEAD
4
35
37
BOLT, 5/16-18x3/4 HEX HEAD GRD5
4
1050
ITEM NO. PART NUMBER
DESCRIPTION
QTY.
36
12B
NUT, 3/8-16, HEX, FULL, GRD 5
1
37
1-0001
BOLT, 3/8-16 x 1 HEX HEAD
1
38
99-0030
WORKREST SUPPORT ASSEM.
1
39
6-0015
PIN, SNAP, SAFTY 3/8" x 3"
1
40
9
SCREW, 10-24x1/2 BH
1
41
5-0035
WASHER, #10, LOCK, HIGH COLLAR 1
42
2061-1
CLIP
1
43
2
BOLT, 5/16-18x1 1/2 HEX HEAD
4
BURR KING
1220 TAMARA LANE
WARSAW, MO. 65355
