MODEL 960-250
PARTS LIST
ITEM 53 LIST - 945
ITEM # PART # DESCRIPTION
1 1 BOLT, 5/16-18x1, HH, GRD 5, PLTD
2 2 BOLT, 5/16-18x1 1/2 HEX HEAD
3 3 NUT, 1/4-20 JAM, PLTD
4 4 WASHER, 5/16 SAE ZINC PLTD
5 5 WASHER, 1/4 AN
6 6 1/4-20 x 1 1/2 FH SOC
7 9 SCREW, 10-24x1/2 BH, BLK OXIDE
8 14 NUT, 10-24, KEP
9 15 WASHER, 5/16 LOCK, SPLIT
10 17 WASHER, 960-616, AN
11 18 WASHER, 960-516, AN
12 20 NUT, NYLOK JAM, 1/2-20
13 21 WASHER, 1/2 ID
14 23 NUT, 6-32, KEP, PLTD
15 24 SCREW, 6-32 x 1/2, MACH
16 26 PIN, 3/32 x 3/8, ROLL PLTED
17 27 SCREW, DRIVE, #8 X 5/8
18 28 SCREW, DRIVE, #2 x 1/4
19 29 SCREW, 10-32 X 1/2 BH
20 30 1/4-20x1 SHCS
21 31 1/4-20x1 1/4 SHCS
22 34 SCREW, 1/4-20 X 1, FH PHILLIPS
23 39 NUT, 3/8-24, JAM, ESNA, NTE
24 40 WASHER, SAE, 3/8
25 MOTOR MOTOR
26 1-0003 3/8-16 x 1 1/4 HEX HEAD BOLT
27 1-0019 BOLT, 5/16-18x1 1/2 HEX HEAD
28 2-0001 1/4-20x1 1/4 SHCS
29 2-0023 SCREW, 10-24 X .625 ALLEN HEAD
30 4-0009 NUT, 3/8-16, JAM, PLTD
31 4-0013 NUT, KEP, 1/4-20
32 5-0014 WASHER, LOCK 3/8, INTERNAL STAR
33 5-0032 WASHER, 1/4, LOCK, SPLIT, PLTD
34 5-0036 WASHER, #8, LOCK, INTERNAL
35 6-0014 PIN, 1/8 X 3/4, ROLL PLTED
ITEM # PART # DESCRIPTION
67 940 SUPPORT, IDLER WHEEL
68 935 SUPPORT, REAR WHEEL
69 937G HANDLE
70 736 RACHET
71 939 GUIDE, SPRING
72 738 SPRING, BELT TENSION
73 25 SCREW, SET, 5/16-18 X 3/8, ALLEN
74 937C STRIP
75 737A KNOB, REAR TENSION ARM
76 737B-1 BUTTON
77 737D SPRING, BUTTON
78 737E NIPPLE, PIPE
79 737F PAWL
80 26 PIN, 3/32 x 3/8, ROLL PLTED
81 27 SCREW, DRIVE, #8 X 5/8
82 28 SCREW, DRIVE, #2 x 1/4
ITEM # PART # DESCRIPTION
36 429 BELT, V DRIVE
37 701 BEARING, CONTACT WHEEL ASSY
38 725 PULLEY, 2 1/2
39 726 WASHER, SPRING FLANGE
40 727 NUT, 5/8-18 RH, JAM, BRT PLT
41 730 PULLEY, 3
42 802 CONTACT WHEEL, 7x2.5, 55 DURO
43 903 GUARD, CONTACT WHEEL
44 904A PLATEN
45 907 WHEEL, IDLER, 7x2.5
46 908 ADAPTER, C-FACE MOTOR
47 920 STUD 3/8"x1 1/2", DOUBLE
48 921 KNOB, TRACKING ASSY
49 922 LOCK, KNOB, TRACKING
50 923 BRACKET, TRACKING
51 924 SUPPORT, BACKUP
52 941 BASE
53 945 QUICK CHANGE, REAR WHEEL
54 705-1 ARM, WORKREST SUPPORT
55 706-1 WORKREST, ANTI-TILT
56 742H GROMMET, SAFETY GUARD DOOR
57 742L LATCH, SAFETY GUARD DOOR
58 900A FRAME/GUARD ASSY, 960-250
59 904B BRACKET, PLATEN
60 942A GUARD, SAFETY, PAINTED
61 942B-1 DOOR, GUARD, NEW STYLE, PAINTED
62 942C-2 STANDOFF, DOOR
63 701B BEARING, 5/8 x 1 3/8 x .432
64 701F WHEEL, IDLER CIR-CLIP
65 707C SHAFT, BEARING
66 742E HINGE
BURR KING
1220 TAMARA LANE
WARSAW, MO. 65355
