Phottix Mitros for Canon User Manual

Page 10

ETTL Modes

A+B+C All three groups fire at an average of the total calculated output.
A:BC Groups A and B can be set by Flash Ratio (see below). Group C is inde-

pendent with its flash output level assigned by the camera.
The EV compensation of Groups A and B can be adjusted.
1. Press the button after exiting the Flash Ratio Setting Screen.
2. Press the or buttons to adjust up or down EV for Groups

A and B.
3. The EV compensation for Group C can also be adjusted.
4. Pressing the button after setting the flash ratio will move the high-

lighted selection to EV adjustment for Group C.
5. Press the or buttons to adjust the EV for Group C.
A:B Groups A and B can be set by Flash Ratio (see below). Group C is not

adjustable and does not fire.
The EV compensation of Groups A and B can be adjusted.
1. Press the button after exiting the Flash Ratio Setting Screen.
2. Press the or buttons to adjust up or down EV for Groups

A and B.

Setting and Adjusting Ratio Modes
ETTL Modes

1. Press and hold the button for 2 seconds to enter wireless mode.
2. Pressing the and buttons will cycle between Master with

flash, Master without flash, Slave, OS and Off modes.
3. Select Master with flash or Master without flash.
4. Pressing button will change the highlighted selection from Master

to Channel and Ratio.
5. Select the transmission channel.
6. Select the Ratio mode. Pressing the and buttons will cycle

between A+B+C, A:B and A:BC modes.
7. When A:B or A:BC are highlighted pressing the button will highlight

the ratio adjustment selection below the ratio.
8. Pressing the button will change the ratio from 1:1 to 1:8 in steps of

1:1.5, 1:2, 1:3, 1:4, 1:6, 1:8.
9. Pressing the button will change the ratio from 1:1 to 1.5:1, 2:1, 3:1,

4:1, 6:1, 8:1.
10. Press the button to confirm and exit the screen.

Manual Modes

A+B+C In manual mode all three groups fire at the same output level. This

power level can be set.
A:B:C The output level of each group is individually adjusted by the user (see

below). Each group is independent, one not affecting the other.
A:B Groups A and B power level can be set individually by the user (see be-

low). Group C is not adjustable and does not fire.

Setting and Adjusting Manual Modes

1. Press the button to change the flash into Manual (M) Mode.
2. Press and hold the button for 2 seconds to enter wireless mode.

3. Pressing the and buttons will cycle between Master with

flash, Master without flash, Slave, OS and Off modes.
4. Select Master with flash or Master without flash.
5. Pressing button will change the highlighted selection from Master

to Channel and Ratio.
6. Select the transmission channel.
7. Select the Ratio mode. Pressing the and buttons will cycle

between A+B+C, A:B and A:B:C modes.
8. Press the button to confirm and exit the screen.
9. Press the button to adjust power levels.
10. Pressing the or buttons will change the Flash Power Level

(1/1 to 1/128 in 1/3rd stops).
11. Pressing the button will change the Groups from A to B to C,

the button from C to B to A (if applicable).
12. Press the button to exit power level adjustment mode.

Multi Mode

A+B+C All three groups fire in Multi Mode at the same power level, frequen-

cy and flash count.
A:B:C The output level of each group is adjusted individually by the user (see

below). The frequency and flash count of the multi strobe of each group are

same and can only be adjusted on Group A.
A:B Groups A and B can be set by power level individually by the user (see

below). The frequency and flash count of the multi strobe of Groups A and

B are same and can only be adjusted on Group A. Group C is not adjustable

and does not fire.

Setting and Adjusting Multi Mode

1. Press the button to change the flash into Multi Mode.
2. Press and hold the button for 2 seconds to enter wireless mode.
3. Pressing the and buttons will cycle between Master with

flash, Master without flash, Slave, OS and Off modes.
4. Select Master with flash or Master without flash.
5. Pressing button will change the highlighted selection from Master

to Channel and Ratio.
6. Select the transmission channel.
7. Select the Ratio mode. Pressing the and buttons will cycle

between A+B+C, A:B and A:B:C modes.
8. Press the button to confirm and exit the screen.
9. Press the button to adjust power levels.
10. Pressing the or buttons will change the Flash Power Level

(1/1 to 1/128 in 1/3rd stops).
11. Pressing the buttons will change the Groups from A to B to C,

the button from C to B to A (if applicable), and allow power level to

be changed on these groups.
12. Pressing the button after cycling through the groups will move to

the frequency and flash count selections.
13. Pressing the or buttons will allow changes to be made to

frequency and flash count. These setting can only be changed on Group A

and will be applied to Group B or C (if applicable).
14. Press the button to exit power level adjustment mode.
