SPECIFICATIONS
GENERAL
Model:
American Audio
®
TTD-2400 - Direct Drive Phono Turntable
System:
2-Speed Direct Drive Phono Turntable Table
Dimensions:
17.72” (W) x 13.7” (D) x 5.4" (H)
450 (W) x 350 (D) x 139 (H) mm
Installation:
Place on flat surface or mount in flat case
Weight:
22 Lbs. / 9.5 Kgs
Power supply:
AC 115v~60Hz/230v~50Hz
Power consumption:
9W
Environmental conditions:
Operational Temperature: 5 to 35˚C (41 to 95˚F)
Operational Humidity: 45 to 85% RH (non-condensation)
Storage Temperature: -10 to 60˚C (4 to 140˚F)
Accessories:
Instruction Manual,
Headshell,
45 RPM Adaptor
TURNTABLE SECTION
Type:
2 Speed Fully Manual
Motor:
8 Pole, 2 Phase, Brushless DC Motor
Driving Method:
Direct Drive
Turntable Platter:
330 mm dia. Aluminum Diecast
Speeds:
33-1/3 and 45-rpm
Wow and Flutter:
Less than 0.15% WRMS (JIS WTD) with 331/3rpm
S/N Ratio:
More than 50dB (DIN-B)
Pitch Controls:
+/- 10%
Starting Torque:
More than 1 kgf.cm
Braking System:
Electronic brake
Starting Time:
Less than 1 sec.
Braking Time:
Less than 1 sec.
Time for Speed Change:
Less than 1 sec. from 33 to 45 rpm.
Less than 1 sec. from 45 to 33 rpm.
High of Cue (first track):
6~10 mm
Descend of Cue:
5 sec.
TONEARM SECTION
Type:
Static balanced straight shaped tonearm with detachable headshell
Effective Arm Length:
220mm
Overhang:
10mm
Tracking Error Angle:
Less than 3 degree
Tracking Force Adjustment Range: 3-4g
Applicable Cartridge Weight:
6-10g
Anti-skating Range:
0-7g
Output:
1.5-3.6mV at 1KHz 5cm/sec
Frequency Response:
20Hz - 20KHz
Channel Separation:
More than 15 dB
Channel Balance:
Within 2.5dB at 1KHz
Needle Pressure range:
2.5g
SPECIFICATION
DESCRIPTIONS
UNIT
NORMAL
LIMIT
Output Difference::
dB
2.3
2.54
Output Level:
mv
1.7~3.5
1.5~3.6
Speed (Speed Range) +/- 10%
Hz
2.7K ,3.3K
2710 ,3290
Speed (Center Range)
Hz
2995~3005
2990~3010
Wow and Flutter
%
0.13
0.15
Channel separation
dB
16
15
©
