Mount the metal brackets with
the double DIN head unit The position of the copper
coloured holder can be adjusted
to your needs for perfect fit.
(see sample)
Installation Manual Double DIN Kit CAW 2114-07 / CAW 2114-07-RT
1. Insert four Ford Mondeo radio
release keys in the OEM head unit.
3. Place facia plate on the dash-
board.
Push the Metal Frame into the
facia plate
Connect all required circuit points
and push the double DIN head
unit in the metal frame until it
snaps in.
Place the trim frame.
All installation work must be performed by a qualified professional installer only.
The manufacturer / dealer is not liable for any kind of incidential or indirect damages.
2. Remove the OEM head unit by
pulling it towards your direction.
