Kenwood CAW1260-02 - Manual

2-DIN CAW-1260-02
* Mount the plates.
Use this hole
Use this hole
Kenwood DDX6029
We advice to use the following positions.
Other positions are also possible.
Use position 1 marked with a cross.
Use position 3 & 5 marked with an arrow.
Measured from left to right.
Kenwood DDX 7025
We advice to use the following positions.
Other positions are also possible.
Use position 1 marked with a cross.
Use position 14 & 16 marked with an arrow
Measured from left to right.
Installation kit includes the following items:
* 1X 2-ISO 100 mm. metal bracket
* 1X Replacement frame
* 1X Radio trim
* 2X Mounting plates
* 2X Mounting spacers
* 4X Screws
* 2X Radio removal keys
Installation manual for:
Landrover Freelander II 2007 -->
