DDX series DDX8026BT English 89
Next page 3 Next page 3
sitting in the front seat, and set the
right and left positions to the center of
the vehicle interior.
2 Measure the distances from the
reference point to the speakers.
3 Calculate the distance difference in
accordance with the farthest speaker.
50cm
80cm
150cm
+70cm
+0cm
+100cm
Channel Level (DNX9/ DDX8 series) Channel Level (DNX9/ DDX8 series)
You can set the volume at each setup
position.
1 Display the Car Type Setup screen
Touch [ ] > > [ ] > > [Audio SETUP]
> > [Channel Level]. (page 68)
2 Select a speaker you wish to adjust
2 2 2
1 1 1
4 4 4
3 3 3
5 5 5
6 6 6
1 Center speaker
2 Left front speaker
3 Right front speaker
4 Left rear speaker
5 Right rear speaker
6 Subwoofer
[Test Tone] Starts or stops test signal
tone output for setup check.
3 Adjust the volume
