DESIGNER SOLUTIONS
3
Operation of this equipment in a residential
area is likely to cause harmful interference
in which case the user will be required to
correct the interference at his own
expense.
•
Any changes or modifications to the unit
not expressly approved by ALTINEX, Inc.
could void the user’s authority to operate
the equipment.
ABOUT YOUR TNP100-HB 2
The TNP100-HB is designed for installation into a
conference room table. The TNP100-HB Tilt ‘N
Plug™ Interconnect Box provides a means of
connecting audio, video, control, and computer video
sources into a presentation system. It is ideal for use
together with ALTINEX computer video interfaces.
The TNP100-HB Tilt ‘N Plug™ Interconnect Box can
either pop up and “tilt” to a raised position to provide
access to the connectors or it can be lowered into a
table when not in use. A pneumatic shock inside the
TNP100-HB’s tower type construction applies
pressure to the panel mechanism, making it easy to
raise and secure the unit firmly in an open position.
Also, for safety, the chassis of the TNP100-HB is
connected to the ground pin of the power plug.
The Tilt ‘N Plug™ Interconnect Box has one input
plate on the front panel of the unit. The standard
plate offers Computer Video (15-pin HD); Audio
(Stereo Mini), Modem (RJ-11), Network (RJ-45) and
Microphone (XLR 4-pin) input connections. All
signals are passed through to a set of female
connectors or cables. Several optional connectors
can be substituted for the standard set of
connectors. For additional information regarding
optional connectors, contact the ALTINEX Sales
Department.
The Tilt ‘N Plug™ Interconnect Box is designed for
use with tables ranging from one to three inches
thick. The Tilt ‘N Plug™ comes in a standard matte
black color; however, it can be finished to match the
table. This is available on a custom per order basis
at an additional charge.
TECHNICAL SPECIFICATIONS 3
FEATURES/
DESCRIPTION
TNP100-HB
GENERAL
Front Panel
Standard
Configuration
Connectors
Faceplate
Cable end
under table
Power
1 outlet with one
circuit breaker
1 plug with 6ft
cord
Computer Video 1 15-pin HD-F 1 15-pin HD-F
Audio
1 3.5mm stereo
female jack
1 3.5mm stereo
male plug
Telephone 1 RJ-11 F
(6-position)
1 RJ-11-M
(6-position)
Network 1 RJ-45-F
(8-position)
1 RJ-45-M
(8-position)
Microphone
XLR 4-pin male
receptacle
XLR 4-pin
female plug
Table 1. TNP100-HB General
MECHANICAL TNP100-HB
Width (inches) 6.03in (153mm)
Height (closed) 4.79in (122mm)
Height (opened) 8.05in (205mm)
Depth (inches) 7.56in (192mm)
Finish Flat Black
T
°
Operating 10
°
C-35
°
C
T
°
Maximum 50
°
C
Humidity 90
%
non-condensing
Table 2. TNP100-HB Mechanical
ELECTRICAL TNP100-HB
Power
Power Rating (pass through
connector) 90-140 VAC, 5Amps
Max
Table 3. TNP100-HB Electrical
