TK-2400VP/3400UP
Compact VHF/UHF FM 2-Watt Portable Radios
The compact ProTalk ® business radios
TK-2400VP/3400UP – are Kenwood’s latest
portable two-way radios. Offering the ideal
solution for communications in construction,
manufacturing and warehousing, retail,
hospitality, facility management and rental
fleet applications. Elegantly engineered to
provide superb ease of use and audio
clarity, even in noisy environments, it also
boasts rugged reliability for dependable
communications in all weather conditions.
COMPACT DESIGN
Ergonomically contoured for comfort, the ProTalk ®
naturally fits the hand for a sure grip. Featuring a
non-slip elastomer channel knob with improved
torque characteristics, it ensures positive response
while avoiding accidental changes.
4 & 16 CHANNEL MODELS
ProTalk ® 4 and 16 channel models are available to
match your needs and requirements, offering ample
capacity for multiple channels or radio systems.
• 4 channel (VHF: TK-2400V4P, UHF: TK-3400U4P)
• 16 channel (VHF: TK-2400V16P, UHF: TK-3400U16P)
FREQUENCY & QT/DQT
(Narrowband Compliant)
Users can program a ProTalk ® to any of the pre-stored
frequencies and QT/DQT codes, thus assuring
compatibility with other brands. The ProTalk
® VHF
(TK-2400VP) 4 and 16 channel models have 27
pre-stored frequencies while the ProTalk
® UHF
(TK-3400UP) 4 and 16 channel models have 90.
Whichever model you pick, there are 39 QT tones and
168 DQT codes*.
For licensing information, please contact the FCC at
http://www.fcc.gov
*QT & DQT may also be referred to under other brand acronyms
as PL, CG, CTCSS & DPL, DCG, DCS.
SUPER LOCK
An added convenience: managers can ‘‘Super Lock’’
all user controls (except PTT and volume) to prevent
accidental channel changes.
WIRELESS CLONING
This feature simplifies the setting up of multiple ProTalk ®
radios for identical functions, eliminating the need to
customize individual radios. (Dealer function only)
CALLING ALERT
This is useful for attracting the attention of staff in
noisy environments: pressing the Calling Alert key
causes an alert tone to be heard from the other
radio’s speaker.
INTERNAL VOX/HANDS FREE READY
In many circumstances, workers do not have a free hand
to use their radio. VOX (voice-operated transmission)
is invaluable for enabling smooth, hands-free
communications: the radio itself provides automatic
PTT action, while the user simply talks. VOX works
with a Kenwood-compatible headset.
TOUGH & WATER RESISTANT
Expertly engineered for rugged work environments,
the ProTalk
® has been designed to pass industrial
drop tests, international IP54/55 water and dust
intrusion tests and 11 categories of the U.S.
Department of Defense MIL-STD 810 C, D, E, F & G
environmental standards tests.
2 WATTS TRANSMIT POWER / RANGE UP
to 6 MILES
Kenwood’s ProTalk ® provides 2 watts of RF power to
enable direct radio-to-radio communications on the
same frequency (simplex) for distances of up to 6 miles*.
*Talk range will vary based on terrain, conditions and type of radio .
OTHER FEATURES
• Voice Annunciation • Time Out Timer • Battery Save
• Low-Battery Warning • Channel Confirmation Mode
• Programmable Frequency Scrambler by Channel
• 4-color LEDs (blue, red, orange, green) • 2 Year Radio Warranty
Conditions TK-2400VP TK-3400UP
Open areas without Up to 6 miles Up to 6 miles
obstructions (9.6 km) (9.6 km)
In steel and/ or concrete Up to 220,000 sq. ft. Up to 250,000 sq. ft.
reinforced buildings (20,400 SQ. M) (23,220 SQ. M)
In high-rise buildings Up to 13 floors Up to 20 floors
2 Year Warranty
