Specifications
Options
All accessories and options may not be available in all markets.
Contact an authorized Kenwood dealer for details and complete list of all accessories and options.
Applicable MIL-STD & IP
ADS#04412 Printed in USA
footnotes from Front:
1 Two-Tone Decode (3 sets x 2 pairs each); Single / Two-Tone
Encode (1 tone).
2 DTMF Encode: PTT ID, Emergency ANI, Auto-Dial (8 numbers),
DTMF Decode: Selective Call (10-digit ID Code, Group Codes;
A, B, C, D & Wild Card characters), and Radio Stun.
3 Special Alert Tone Pattern operates for 2-Tone, DTMF, FleetSync ®
selective call decode.
4 KPG-128D required: Windows ® 2000/XP/Vista compatible.
5 ID List capacity is 8 ID's; 10 Group ID's; Status 1 & 2 (10~99).
Model TK-2360 TK-3360
GENERAL
Frequency Range
Type 1 136-174 MHz 450-520 MHz
Type 2 – 400-470 MHz
Number of Channels Max. 16
Channel Spacing
Wide/Narrow 25, 30kHz/12.5,15kHz 25kHz/12.5kHz
Operating Voltage 7.5V DC±20%
Battery Life (5-5-90 duty cycle, save off)
with KNB-55L (1480 mAh) Approx. 9 hours
with KNB-56N (1400 mAh) Approx. 9 hours
with KNB-57L (2000 mAh) Approx. 13 hours
Operating Temperature Range -22°F ~ +140°F (-30°C ~ +60°C)
[-14°F ~ +140°F (-10°C ~ +60°C)
when KNB-55L/57L in use]
Frequency Stability ±2.5ppm (-22°F ~ +140°F)
Antenna Impedance 50 Ω
Channel Frequency Spread
38MHz 70MHz
Dimensions (W x H x D), Projections not included
Radio Only 2.2” x 4.1” x 0.55” (56 x 103.7 x 14.0mm)
with KNB-55L 2.2” x 4.1” x 1.14” (56 x 103.7 x 29.1mm)
with KNB-56N 2.2” x 4.1” x 1.33” (56 x 103.7 x 33.8mm)
with KNB-57L 2.2” x 4.1” x 1.18” (56 x 103.7 x 30.1mm)
Weight
Radio Only 5.75oz (163g)
with KNB-55L 9.17oz (260g) without antenna
with KNB-56N 12.70oz (360g) without antenna
with KNB-57L 10.05oz (285g) without antenna
FCC ID
Type 1 ALH415000 ALH415100
Type 2 – ALH415101
Model TK-2360 TK-3360
RECEIVER (Measurements made per TIA/EIA-603)
Sensitivity (12dB SINAD)
Wide/Narrow 0.25µV/0.28µV
Selectivity
Wide/Narrow 70dB/63dB
Intermodulation Distortion
Wide/Narrow 68dB
Spurious Response 70dB
Audio Distortion Less than 5%
Audio Output 500 mW / 8 Ω
TRANSMITTER (Measurements made per TIA/EIA-603)
RF Power Output
High/Low 5W / 1W
Spurious Response 70dB
Modulation
Wide/Narrow 16KØF3E/11KØF3E
FM Noise
Wide/Narrow 45/43dB
Audio Distortion Less than 5%
■ KNB-55L
Li-ion Battery Pack
(1,480mAh)
■ KNB-56N
Ni-MH Battery Pack
(1,400mAh)
■ KNB-57L
Li-ion Battery Pack
(2,000mAh)
■ KNB-40LCV
Li-ion Battery Pack
(1,950mAh)
■ KBP-5
Battery Case
■ KSC-25
Rapid Charger
■ KSC-30
Regular Charger
for KNB-56N
■ KSC-256K
Six Unit Gang Charger
■ KRA-22
VHF Low Profile
Helical Antenna
■ KRA-23
UHF Low Profile
Helical Antenna
■ KRA-26
VHF Helical Antenna
■ KRA-27
UHF Whip Antenna
■ KMC-45
Speaker Microphone
■ KMC-21
Speaker Microphone
■ KEP-2
Earphone Kit for
KMC-45 (2.5mm plug)
■ KHS-22
Head Set
■ KVC-3
Regular Rate Vehicular
Charger Adapter
(for KSC-30)
■ KVC-4
Rapid Rate Vehicular
Charger Adapter
(for KSC-25)
■ KHS-7A
Lightweight Single
Muff Headset
■ KHS-8BL
2-wire Palm Mic with
Earphone (Black)
■ KHS-9BL
3-wire Lapel Mic
with Earphone (Black)
■ KLH-138
Leather Case
■ KBH-12
Belt Clip
Standards Methods/Procedures Methods/Procedures Methods/Procedures Methods/Procedures
MIL-STD 810C MIL-STD 810D MIL-STD 810E MIL-STD 810F
Low Pressure 500.1/Procedure I 500.2/Procedure I, II 500.3/Procedure I, II 500.4/Procedure I, II
High Temperature 501.1/Procedure I, II 501.2/Procedure I, II 501.3/Procedure I, II 501.4/Procedure I, II
Low Temperature 502.1/Procedure I 502.2/Procedure I, II 502.3/Procedure I, II 502.4/Procedure I, II
Temperature Shock 503.1/Procedure I 503.2/Procedure I 503.3/Procedure I 503.4/Procedure I, II
Solar Radiation 505.1/Procedure I 505.2/Procedure I 505.3/Procedure I 505.4/Procedure I
Rain 506.1/Procedure I, II 506.2/Procedure I, II 506.3/Procedure I, II 506.4/Procedure I, III
Humidity 507.1/Procedure I, II 507.2/Procedure II, III 507.3/Procedure II, III 507.4
Salt Fog 509.1/Procedure I 509.2/Procedure I 509.3/Procedure I 509.4
Dust 510.1/Procedure I 510.2/Procedure I 510.3/Procedure I 510.4/Procedure I, III
Vibration 514.2/Procedure VIII, X 514.3/Procedure I 514.4/Procedure I 514.5/Procedure I
Shock 516.2/Procedure I, II, V 516.3/Procedure I, IV 516.4/Procedure I, IV 516.5/Procedure I, IV
International Protection Standard
Dust & Water Protection IP54/55
Specifications are subject to change without notice, due to advancements in technology.
Windows ® is a registered trademark of Microsoft Corporation in the United States and other countries.
FleetSync ® is a registered trademark of JVC KENWOOD Corporation in the United States and/or other countries.
All other trademarks are property of their respective owners.
KNB 55L
KSC-25
KVC-3
*To meet IP54/55, the 2-pin connector cover has to be connected on the radio or the locking bracket has to be attached to the KMC-45 external speaker microphone.
