Specifications/Features & Benefits/Package Contents
Table 1
Features & Benefits
1. Peak Output—2000 Watts
2. Rated Output—1800 Watts
3. Single Phase 60 Hz
4. On/Off Switch
5. Voltmeter
6. Low Oil Shut Off
7. Separate Ground Connector
8. Generator/Motor on Rubber Mounts
9. 12 Volt DC Circuit, 8.3 Amps, Battery Charger
10. All Outlets Circuit Protected
11. 2 x 120V AC, 20 Amp Grounded (5-20R)
12. Dual 120/240V AC, 12.5A Twist Lock (L14-30)
13. 5.5 HP Engine rated at 3600 RPM, 163cc
14. Spark Arrestor Muffler
15. TCI Ignition
16. Gas Tank, 4.0 Gal, with Input Fuel Filter
17. Fuel Shut Off with Internal Fuel Filter
18. Noise Level of 67 dB(A) @ 24 Ft.
19. Run Time of 11 Hours at 50% Load
Package Contents
1. Generator
2. Operator’s Manual
3. Warranty Card
4. Spark Plug Wrench
Generator Ratings Engine
Type Brush Single Phase Engine Type & Displacement OHV Single Cylinder 163cc
Voltage Regulate AVR Maximum Output HP/RPM 5.5/3600
AC Rated Output 2.0kW/2000 Watts Oil Capacity .63 Qt. (.6 Liter)
AC Maximum Output 1.8kW/1800 Watts Low Oil Shut Down Standard
AC Voltage 120V/240V Fuel Type Gasoline
AC Frequency 60 Hz Fuel Capacity 4.0 Gallons
120 VAC Amperage Rated 15/Max 17 Run Time @ 1/2 Load 13 Hours
240 VAC Amperage Rated 7.5/Max 8.3 Operating Noise Level 67 dB(A) @ 24 Ft.
DC Voltage 12V Battery Charger Outlets
DC Amperage 8.3 Amps 1 x 12V DC 8.3 Amp Connector
Dimensions & Weight 2 x 120V 20 Amp Grounded
Dimensions (inches) 23.6 x 17.7 x 18.5 1 x Dual AC 120/240V 12.5 Amp Twist Lock, 4 Prong (L14-30)
Weight 86.0 Lbs.
