Dake Dura Press Force - 10/25 User Manual
Page 7
Force 10DA & Force 25DA
7
ITEM
DESCRIPTION
QTY
10DA
Part No.
25DA
Part No.
REMARKS
1
Frame
1
86517
86684
2
1/2" - 13NC x 2 3/4"
4
43355
43355
LG. Hex Cap Screw
3
1/2" Channel Washer
4
43657
43657
4
Workhead Assembly
1
716514
716640
5
1/2" Lock Washer
4
43647
43647
6
1/2" - 13 Hex Nut
4
43916
43916
7
Base Angle
2
85189
978
8
1/2" - 13NC LG.
4
43349
43347
Hex Cap Screw
9
Table Pin
2
86520
85407
9A
Retaining Ring
2
43975
76818
11
Table Channel
1
86692
86682
12
1/2" Lock Washer
4
43647
43644
13
1/2" - 13 Hex Nut
4
43916
43916
20
Nose Piece
1
86691
86683
23
Hydraulic Power Unit
1
300266PU
300265PU
does not include Gauge, Fittings,
Hoses and Valve
Gauge, Fittings, Hoses and
Valve
1
300266KIT
300265KIT Gauge, Fittings, Hoses and Valve
24
5/16" - 18NC x ½"
4
43313
43313
LG. Hex Cap Screw
25
5/16" Flat Washer
4
43632
43631
27
Warning Label
1
84487
84487
(See Page 10)
28
Warning Label
1
84399
84399
(See Page 10)
29
3-IN-1 Warning Label
1
300168
300168
(See Page 10)
30
Safety Instructions
1
76462
76462
(See Page 10)
31
Warning Label
1
84395
84395
(See Page 10)
32
DAKE Name Plate
1
86533
86534
(See Page 10)
33
Made In USA Plate
1
76936
76936
(See Page 10)
34
Table Plates
2
85427
85508
Conversion tons to psi Label
1
79955
79964
CONVERSION CHART LABEL
PARTS NOT ILLUSTRATED
Breather Vent and elbow
1
300267
300267
Reservoir fill port
Eyebolts
2
N/A
300284
Triangular Snap Hooks
4
N/A
300285
Coil Chain
2
N/A
78477
Gauge
1
301315
301316
Reads in tons / psi
Gauge
1
301315
300268
Reads in bar / psi
Reservoir
1
300269
300269
2 gallon
Optional check valve
1
302071
302071
Check valve
Optional relief valve
1
301949
301949
290-3625 psi or 20-250 bar
Optional relief valve
1
302197
302197
43.5-435 psi or 3-30 bar
Bolts
4
43401
43401
Mounting bolts for valve only
Bolts
4
76749
76749
Mounting bolts for valve and relief
valve or check valve
Bolts
4
302221
302221
Mounting bolts for valve, check
valve and relief valve.
