CATRAC
®
Options
25
6380 Brockway Road • Peck, MI 48466 • 800.325.8074 • 810.378.5511 • Fax 810.378.5516 • www.ametekapt.com
Chip Covers
Stainless steel chip covers protect hoses against damage
from hot metal chips. The chip covers fi t over the full
length of the CATRAC
®
assembly, on either the top or
bottom or both sides for maximum protection. The ends
of the chip covers extend six inches beyond the ends
of the CATRAC assembly for attachment. Chip covers
should be fastened on either end to allow them to roll
with the CATRAC. When ordering, specify either outside
or inside covers or both.
Heavy Duty Mounting Feet
Heavy Duty horizontal and vertical mounting feet are
made from 3/16” or 1/4” plate steel and provide the
ultimate in strength at the mounting point. Typical
applications include mill duty equipment and high speed
applications. Custom designs are also available upon
request.
Glide Bars and Transfer Bar for Side Mounted
Applications
We offer a wide range of options for side mounted
applications including Nylatron glide bars, round pads
and steel or stainless steel ball casters. We can side
mount virtually any style of CATRAC. Dual radius
CATRACS are also available for rotary applications.
Multiple Carrier Widths
All styles of 3 Pin Center Pivot CATRAC are available
in multiple widths. This type of construction provides
additional strength in wide systems. When width is
a problem double decking of compartments is also
available.
CATRAC
®
Options
Transfer Balls
Alternated for
Stability
