12
Probes
To get the most out of your scope,
you need the right probes and
accessories for your particular
application. That's why Agilent
Technologies offers a complete
family of innovative passive and
Selection guide
10073C (shipped
10074C (shipped with 6000 Series
with 6000 Series 300 MHz - 1 GHz 10076A N2771A
Agilent passive probes 10070C 100 MHz models) models) high-voltage probe high-voltage probe
Probe bandwidth 20 MHz 150 MHz 500 MHz 250 MHz 50 MHz
Probe rise time (calculated) <17.5 ns <2.33 ns <700 ps <1.4 ns <7 ns
Attenuation ratio 1:1 10:1 10:1 100:1 1000:1
Input resistance (when 1 M
Ω
10 M
Ω
2.2 M
Ω
66.7 M
Ω
100 M
Ω
terminated into 1 M
Ω)
Input capacitance Approx. 70 pF Approx. 15 pF Approx. 12 pF Approx. 3 pF Approx. 1 pF
Maximum input 400 Vpk CAT I 500 Vpk CAT I 500 Vpk CAT I 4000 Vpk 15 kV dc, 10 kVrms,
(dc+peak ac) (mains isolated) (mains isolated) (mains isolated) 30 kV dc + peak ac
400 Vpk CAT II 400 Vpk CAT II 400 Vpk CAT II
(post receptacle (post receptacle (post receptacle
mains) mains) mains)
Compensation range None 9-17 pF 6-15 pF 6-20 pF 7-25 pF
Probe sense No Yes Yes Yes No
Current probes Description
1146A 100 kHz current probe, ac/dc
N2774A 50 MHz current probe, ac/dc
N2775A Power supply for N2774A
1147A 50 MHz current probe, ac/dc with AutoProbe interface
Active single-ended probes Description
1144A 800 MHz active probe
1145A 2-channel 750 MHz active probe .
1142A Power supply for 1144A/1145A
1156A 1.5 GHz active probe with AutoProbe interface
Active differential probes Description
N2772A 20 MHz differential probe
N2773A Probe power supply for N2772A
1130A 1.5 GHz InfiniiMax differential probe amplifier with AutoProbe interface (Order one or
more InfiniiMax probe heads or connectivity kits per amplifier.)
Note:
These Infiniium active probes are not supported by 6000 Series 300 MHz - 1 GHz models – 1152A, 1153A, 1154A, 1155A, 1159A, 1168A, and 1169A. The 6000 Series 100 MHz
models do not support any Agilent Infiniium active probes with AutoProbe interface.
active probes for the 6000 Series
scopes to get your job done easily.
For more comprehensive
information, refer to the Agilent
6000 Series Oscilloscopes Probes and Accessories Data Sheet
(Agilent publication number
5968-8153EN/ENUS). You can get
a copy by visiting our Web site at:
www.agilent.com/find/MSO6000.
