SECTION IX
PROCEDURE FOR FUNCTIONAL CHECK
OF REPLACEMENT COMPONENTS
KEYBOARD (TOUCH PAD) LAYOUT
1. Liquid Crystal Display
2. Top Pocket HI Key
3. Top Pocket MED Key
4. Top Pocket LO Key
5. Top Pocket PAUSE Key
6. Bottom Pocket HI Key
7. Bottom Pocket MED Key
8. Bottom Pocket LO Key
9. Bottom Pocket PAUSE Key
