SPIRAL BEVEL GEARBOXES RANGE “N”
5.
General Assembly & Parts List
5.1
General arrangement – Ratio 1:1 & 1.5:1
5.1.1 Parts List - Ratio 1:1 & 1.5:1
2 way /
2 way reverse
3 way
3 way reverse
4 way
Item No
Description
Qty Qty Qty Qty
1 Input
Shaft
1
1
2
2
2 Output
shaft
1
1
1
1
3
External Shaft Key
2
3
3
4
4
Shaft End Cap
2
3
3
4
4a Blank
Cover
1
0
1
0
5 Oil
Seal
2
3
3
4
6 O
Ring
3
3
4
4
7 Outer
Bearing
3
3
4
4
8 Inner
Bearing
1
1
2
2
9 Gear
Case
1
1
1
1
10 Internal
Key
2
2
3
3
11 Set
Screw*
12
12
16
16
12
Mitre Gear – Left hand
1
1
2
2
13
Mitre Gear – Right hand
1
1
1
1
14 Spring
Washer*
12
12
16
16
15
Oil Fill / Drain Plug
3
3
3
2
16 Circlip
1
1
2
2
17 Shim
4
4
8
8
18 Gaskets
-various
thickness
8
8
12
14
* Exact number depending upon unit size – please consult Neeter Drive
17
15
9
2
11
14
18
(4a)
12
16
10
8
6
4
3
5
1
7
13
