E-54
Continuous power output, per channel, 8Ω
2 channels driven, 20Hz - 20kHz, <0.02% THD
100W
2 channels driven, 1kHz, 0.2% THD 125W
7 channels driven, 1kHz, 0.2% THD 90W
residual noise & hum <0.3mV
inputs
Line inputs:
nominal sensitivity
1V, 2V, 4V (user adjustable)
Input impedance 47k Ω
Signal/noise ratio (CCIr, 100W) 100dB
Preamplifier outputs
nominal output level
1V rMS
Output impedance 560 Ω
THD+n (20Hz—20kHz) -100dB
Video inputs
Component video signal/noise
85dB
Composite video signal/noise 70dB
Headphone output
Maximum output level into 32
Ω 2Vrms
Output impedance <5 Ω
General
Mains voltage
110–120V or 220–240V, 50 –60Hz
Power consumption (maximum) 1.5kW (Thermal dissipation approx. 5200 BTU/hour)
Power consumption (idle, typical) 100W (Thermal dissipation approx. 340 BTU/hour)
Power consumption (standby) <0.5W
Dimensions
W x D (including speaker terminals) x H (including feet)
433 x 425 x 171mm
Weight (net) 15.5Kg
Weight (packed) 20Kg
Supplied accessories Mains lead
Cr102 remote control
4 x AAA batteries
Manual
DAB aerial
FM aerial
AM loop aerial
Calibration microphone
E&OE
note: All specification values are typical unless otherwise stated.
Continual improvement policy
Arcam has a policy of continual improvement for its
products. This means that designs and specifications
are subject to change without notice.
specifications
