4. Tone: Use this control to adjust the balance of the high and low frequencies. The tone control is functional in both Normal and Boost
modes.
5. Volume: Overall volume adjustment. Turning this knob clockwise (0-10) increases the overall sound level.
6. Pull Boost: Pull this knob to boost the preamp gain. This feature can also be accesed by the footswich.
THE VOLumE kNOB muST BE IN THE PuLLEd POSITION FOR THE FOOTSWIcH TO FuNcTION.
7. Low Input Jack: Connect the cable from the instrument’s output jack to this jack. This jack is provided for instruments that have extremely
high outputs that can result in distortion when connected to the Hi Input Jack. The Low Input Jack also provides a darker tone than the Hi Input
Jack. Always use an undamaged, shielded instrument cable.
8. High Input Jack: Connect the cable from the instrument’s output jack to this jack if it has an average output (i.e., Strat-style and Les Paul-
Style guitars with vintage-style pickups). The High Input Jack provides a brighter tone than the Low Input Jack. Always use an undamaged,
shielded instrument cable.
B. THE REAR PANEL
Fig. 2: The Rear Panel
9. Footswitch Jack : Plug the preamp gain Boost footswitch into this jack.
10. Speak Jacks: Plug a 4-ohm, 8-ohm,16-ohm cabinet into the appropriate jack. The special 6 Combo’s internal speaker is disconnected when an
external jack is used.
11. Power IEc Socket: Use the included power cord with this unit in accordance with the voltage and frequency ratings listed on this manual and
rear panel of this amplifier.
9 10 11
6 7
