Y1-03-0146E

5



SECTION TWO- OPERATING INSTRUCTIONS

a. Turn "ON"

Slide switch up until it stops. The strobe should begin flashing
within a few seconds.

b. Turn "OFF"

Slide switch down until it stops. The unit will stop operating.

c. White Light

With the flashguard shield in the retracted (stored) position, slightly
raise the IR filter and rotate it either left/right 90°, push filter in to
lock into place. (See Figure 2)

Figure 2


d. IR Light

With the flashguard shield in the retracted (stored) position, insure
that the IR filter is resting on the top (vertical) end of the light over
the clear lens, then push filter down to lock into place. (See Figure
3)

Stored

Lift

Rotate

White
