INSTALLATION PROCEDURE

Refer to the attached drawing to clarify installation.

STEP 1:

Remove the nut that holds the eyewash push flag to the valve stem. If the unit is
also foot operated, remove the ring from the end hole of the flag.

STEP 2:

Position the dust cover assembly over the existing

∅11” eyewash receptor. After

checking for the initial alignment, tighten the adjustable strap around the receptor
only enough to keep it from sliding during the installation process.

STEP 3:

Put the flag on the valve stem before attaching the link on it through the first hole
on the link. Secure the flag and the link to the valve stem by tightening the
shoulder nut provided.

STEP 4:

Align the second holes on the flag and the link. Insert the 3/8” – 24 UNC x 1”
screw (with hole) through the holes and tighten it with the nut. Use some
lubricant if necessary.

STEP 5:

If the eyewash is foot operated, reattach the ring connected to the chain into the
hole of the 3/8” – 24 UNC x 1” screw.

STEP 6:

After making sure that the cover and the receptor are properly positioned, tighten
the adjustable strap firmly to secure the dust cover assembly on the eyewash
unit.

STEP 7:

Test the eyewash to ensure the full access and the sufficient water flow while
open.

TROUBLESHOOTING

Before performing any troubleshooting work, inform all related parties of the discontinuation of
service. Service to be performed on equipment by qualified personnel.

PROBLEM

REPAIR CHECKLIST

Cover does not open all the way.

Check for obstructions behind the unit.

If the unit is also foot operated, check the
chain length and adjust it if necessary.

Cover is not aligned with the receptor.

2. a.

Loosen the strap then adjust the link and
the back mounting bracket.
