07/10 Model 8169 Page 2 of 4
LOCATION OF UNIT: The Model 8169 Emergency Shower should be installed in close
proximity to potential accident areas. It should be clearly identified free from obstructions
and easy to access.
SUPPLY LINE: The minimum recommended line size is 1” IPS with 30-90 psi (2-6 ATM)
flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Inlet supply is female 1” IPS.
TROUBLESHOOTING
PROBLEM REPAIR CHECKLIST
1.
No flow.
1.
Check the main shut-off valve.
2. Insufficient water flow at the
showerhead.
2. a. Verify minimum 30 psi (2 ATM)
flowing supply line pressure.
b. Probable clogging of flow control
inside showerhead. Unscrew
showerhead off of 1” x 5” nipple and
clean rubber flow control.
