04/14

Model 8300-8309/8300CRP-8309CRP

Page 2 of 5

LOCATION OF UNIT: The Model 8300/8300CRP/8309/8309CRP Emergency Shower
should be installed in close proximity to potential accident areas. It should be clearly
identified, free from obstructions and easy to access.

SUPPLY LINE: The minimum recommended line size is 1-1/4” IPS with 30-90 psi (2-6
ATM) flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.

PLUMBING CONNECTIONS: Inlet supply is female 1-1/4” IPS. Waste outlet is female
1-1/4” IPS.

INSTALLATION PROCEDURE

Refer to Installation Drawing for clarification. Check parts list to insure all required parts
are included. Use pipe joint sealant PST #565 (Loctite) on all connections.

STEP 1:

Prepare the emergency shower foundation by using the floor flange
assembly as a template. Locate the three holes for the 3/8-16 UNC x 6”
anchor bolts (not supplied). They should extend 1” above the floor level.

STEP 2:

Once the concrete foundation is ready (dry), assemble the floor flange
assembly to the anchor bolts; then securely fasten with 3/8-16 UNC Hex
nuts and 3/8” washers (not supplied). Seal and tighten floor flange and
tee (1-1/4”) making certain the waste tee is facing the proper location and
the foot control holes are facing side to side.

STEP 3: Assemble

nipple

(1-1/4” x 21-1/2”) to the floor flange assembly and tighten

with a pipe wrench.

STEP 4:

Assemble the eyewash loop assembly to the 21-1/2” nipple from Step
three. Connect the pipe wrench to the galvanized nipple between the two
tees to avoid damage.

STEP 5:

Assemble in the following order:

Attach nipple (1-1/4” x 24”) onto the loop assembly.

Attach nipple (1-1/4” x 24”) onto the tee (1-1/4”).

Attach tee (1-1/4” x 1-1/4” x 1”) onto nipple.

Attach nipple (1x 9”) valve assembly onto tee (1-1/4” x 1-1/4” x 1”).

Assemble the street elbow (1”) onto nipple (1” x 12-1/2”).

Attach nipple onto valve.

STEP 6:

Assemble showerhead onto street elbow (1”).

STEP 7:

Assemble the sign onto the unit. Use the strap, screws, washers and nuts
provided to mount the sign onto the upright. The sign should be positioned
for maximum visibility.

STEP 8:

Insert the plug into the optional supply line tee that is not used. Before
connecting the supply water line to the emergency shower, FLUSH THE
LINE THOROUGHLY.
