Haws 3300FR User Manual

Page 2

04/10

Model 3300FR/3300GFR

Page 2 of 4

RECOMMENDED TOOLS: Hack saw, pipe joint sealant, screwdriver, level, 12" adjustable
wrench, 10" pipe wrench, 5/64” hex key wrench, 9/16”, 1/2", 7/16” socket wrench or open
end wrench.

LOCATION OF UNIT: The Model 3300FR/3300GFR Drinking Fountain is a wheelchair
accessible drinking water facility. The height dimensions shown, meet current ADA
requirements. When installing this unit, local, state or federal codes should be adhered to. If
height other than shown is required, then dimensions must be adjusted accordingly.

SUPPLY LINE: The minimum recommended line size is 1/2“IPS with 30-90 psi (2-6 ATM)
flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.

PLUMBING CONNECTIONS: Waste outlet is female 1-1/2” Slip PVC.

MAINTENANCE: Periodically clean the strainer. Refer to 6518.2FR Valve Operation and
Maintenance Sheet for information.

TROUBLESHOOTING

PROBLEM

REPAIR CHECKLIST

Insufficient bubbler flow.

1a. Check that inlet screwdriver stop valve

is wide open. Turn counterclockwise.

b. Verify minimum 30psi flowing supply

pressure.

c. Clean inlet strainer.

d. Adjust valve to increase flow. See

6518.2FR Valve Manual.

General Notes:
Before tightening nut and ferrule assembly, push tubing into fitting until it bottoms out to
ensure correct engagement with O-Ring.

For more information about Haws products, see our website: www.hawsco.com
